►物理测试室简介 / Introduction of Physicaltest Room
测试材料的力学性能、电性能、热性能、微观形貌以及在线测试材料在压缩变形下的电性能和热性能变化。
Test the mechanical properties, electrical properties, thermal conductivity, micro morphology of the materials, and online test the electrical and thermal properties of the materials under compressive deformation.
测试对象包括对导电橡胶、导电胶水、导热材料、绝热材料、吸波材料、导热吸波材料，柔性屏蔽材料、密封材料在内的复合材料以及其他功能材料。
我们也可以为客户提供的材料进行各种物理性能的测试，以方便客户进行优化的设计。
The test objects include composite materials such as conductive rubber, conductive paste, thermal conductive material, thermal insulation material, absorbers, shielding material, sealing material, and other functional materials.
We can also test various physical properties of materials provided by customers to facilitate customers' optimized designs.
•主要测试仪器 / Main Test Instruments
CMT6104微机控制电子万能试验机 / CMT6104 Microcomputer Controlled Electronic Universal Testing MachineHOT-DISC测试仪器 /HOT-DICS Thermal Tester
DL-III型导热系数测试仪 / DL-III Type Thermal Conductivity Tester
体积电阻-表面电阻测试仪 / Volume resistivity-Surface Resistance Tester
压缩率-电阻测试仪 / Compression ratio - resistance tester
GX201A+VM型正置金相显微镜 / GX201A+VM Type Metallographic Microscope
邵氏硬度计 / Shore Hardness Tester
| 仪器名称 | 仪器型号 | 测试项目 | 测试标准 |
| 导热系数测试仪 | DRL-III | 导热系数 | ASTM D5470 |
| 热阻 | |||
| 热常数分析仪 | TPS2500S | 导热系数 | ISO 22007-2:2008 |
| 维纸硬度计 | HVX-1000A | 维氏硬度测试 | GB/T4340.2 |
| 荷重位移曲线测试仪 | S205 | 疲劳度测试 | QA-WI-078（雷兹盾标准） |
| 振实密度测试仪 | BT-301 | 振实密度测试 | |
| 击穿电压试验机 | HJC-50KV | 耐压强度 | ASTM D149 |
| 硬度测试 | LX-A | 邵氏硬度 | ASTM D2240-03 |
| 硬度测试 | GS754G(LX-00) | 邵氏硬度 | JIS6400.6 ASKER F |
| 体积表面电阻测试仪 | GES-121 | 体积电阻率 | ASTM D257 |
| 电阻测试仪+数显式推拉力计 | GOM-802+DS2-1000N | 体积电阻率-表面法 | MIL-DTL-83528C |
| 体积电阻率-压力法 | MIL-DTL-83528C | ||
| 万能密度测试仪 | QL-300AW | 密度 | ASTM D792-A |
| 万能拉力机 | CTM6104 | 拉伸强度和断裂伸长率 | ASTM D412 |
| 撕裂强度 | ASTM-D624 | ||
| 离型力测试 | ASTM D3330 | ||
| 剪切强度测试 | GB/T 7124-2008 |
►化学分析室简介 / Chemical Analysis Laboratory
化学分析室主要用于材料的检验分析和合成改性检验分析包括对有机硅橡胶、有机硅树脂、聚氨酯弹性体、EPDM橡胶、环氧树脂等高分子原材料以及填充改性后复合材料的粘度、可固化性能测试分析，对无机填料的含水率、吸油率和密度测试。
The chemical analysis laboratory is mainly used for analysis & synthesis and modification of materials. Analysis includes viscosity & curing test about organic silicon rubber, organic silicon resin, polyurethane elastomer, EPDM, epoxy resin and filling modified polymer. And it also can test moisture content, oil absorption & density about inorganic filler.
材料的合成改性包括树脂、橡胶的化学改性和功能粉体的表面处理，例如机硅树脂改性环氧树脂，有机硅改性丙烯酸树脂，氮化硼、氧化铝、石墨烯等粉体的表面处理等。
Synthesis and modification of materials include chemical modification & surface treatment of functional powder such as organic silicon resin modified epoxy resin, organic silicon resin modified acrylic resin, surface treatment of boron nitride, aluminum oxide, graphene, etc.
•主要测试仪器 / Main Instrument
化学合成通风柜 / Chemosynthesis fume hood
RVDV1M型旋转粘度计 / RVDVIM type rotary viscometer
JZ-6029型无转子硫化仪 / J Z-6029 type no rotor rheometer
MXD-B1100型高速分散机 / MXD-B1100 type high-speed dispersion machin
| 仪器名称 | 仪器型号 | 测试项目 | 测试标准 |
| 数显恒温水浴锅 | HH2 | 渗油率 | QA-WI-069（雷兹盾标准） |
| 激光粒度分析仪 | LS-POP(9) | 粒径测试 | ASTM B822-10 ISO 13320:2009 |
►可靠性测试实验室简介 / Introduction of Reliability Test Laboratory
可靠性实验室模拟极端使用环境用于测试电子、电工材料和电子元器件耐湿热、耐高温、耐低温、耐温变冲击、耐盐雾腐蚀能力、耐机械冲击、耐碰撞、抗跌落、耐燃烧性、防水和抗压等性能，用于测试电子材料和元器件的使用可靠性，以及预估使用寿命。
The reliability test laboratory is set for simulating extreme environment for testing electronic, electrical materials and electronic components with their heat resistance, high temperature resistance, low temperature resistance, thermal shock resistant, salt spray corrosion resistance, mechanical impact resistance, collision resistance, anti-dropping, burning resistance, waterproof and compressive properties, which can show the reliability properties of electronic materials and components and predict the service life.
•测试仪器 / Test Instrument
DH64-65高低温（湿热）试验箱 / DH64-65 high and low temperature (hot and humid) test chamber
GW100-200高温老化试验箱 / GW100-200 high temperature aging test chamber
DR-60型中性盐雾试验机 / DR-60 type neutral salt spray test chamber
Auto SPA UL94 垂直燃烧仪 / Auto SPA UL94 vertical burning chamber
机械冲击试验机 / Mechanical impact testing machine
跌落试验机 / Drop test machine
| 仪器名称 | 仪器型号 | 测试项目 | 测试标准 |
| 高低温湿热试验箱 | DH64-65 | 温湿热老化测试（恒温恒湿） | ASTM D3574-05 |
| 高温试验箱 | GW100-200 | 干热老化测试（高温） | ASTM D3574-05 |
| 水平垂直燃烧实验仪 | AUTO-SPA | 阻燃测试 | UL94 |
| 盐雾腐蚀试验箱 | DR-60 | 中性盐雾测试 | ASTM B117-2007 |
| 冷热冲击试验机 | LY-TS-50 | 冷热冲击测试 | GBT 2424.1-2005 |
| 模拟运输振动测试仪 | HD-A521-1 | 振动测试 | ISTA&EN71 |
►EMI 测试室介绍 / EMI Test Room Introduction
EMI测试室用于测试吸波材料的反射率和屏蔽材料的屏蔽效能。屏蔽室用于测试材料的高频段屏蔽效能，频率测量范围为200MHz ～ 40GHz，屏蔽效能测量范围为0dB ～ 120dB。反射率弓形测试架用于测试吸波材料的反射率，扫频测试频率1GHz ～ 40GHz，测量0 ~ -40dB。
The EMI test room is used to test the reflectivity of absorbing material & the shielding effectiveness of shielding material. The shielding chamber is used to test the high frequency shielding effectiveness of materials, and the frequency measuring range is from 200MHz to 40GHz with the shielding effectiveness range from 0dB to 120dB. The NRL arch reflectivity test system is used to show the return loss of absorbers, with scanning frequency from 1GHz ~ 40GHz and reflectivity attenuation range of 0 ~ -40dB.
•主要仪器/ Main Instrument
屏蔽室 / Shielding chamber
电动拱形框 / Electric arch shelf
安捷伦5234A型矢量网络分析 / Agilent type 5234A vector network analyzer
发射和接收天线 / Transmit and receive antenna
| 仪器名称 | 仪器型号 | 测试项目 | 测试标准 |
| EMI测试房 | EMI实验房+NA5234A网络分析仪 | 屏蔽效能 | MIL-STD 285 (MIL-G-83528C) |
| 静态压力-压变曲线 | QA-WI-058（航科固邦方法） | ||
| 反射率损耗曲线 | GJB2038A-2011 |
